openEO Processes

An openEO process is an operation that takes one or more inputs, performs a task, and returns a result. In simple terms, processes are the building blocks of an openEO workflow.

Some processes load data, some filter it, some transform it, or some export it. By combining them, users can describe an Earth Observation (EO) workflow in openEO.

As described in the Glossary, a process is an operation that performs a specific task on a set of parameters and returns a result.

Examples include:

In openEO, processes are combined into a process graph. A process graph is the machine-readable description of a workflow: it tells the backend what to do, in which order, and with which parameters.

openEO process workflow overview

What openEO offers

openEO offers a broad catalogue of standardised and a few non-standardised processes that cover most EO analysis tasks. These processes can be further identified as processes for data discovery, for applying operations on the cubes, or for simply exporting the results. Such as:

  • Import processes to load collections, STAC resources, uploaded files, or URLs.
  • Filter processes applied to a datacube to limit data by time, space, bands, labels, or metadata.
  • Reducer and aggregate processes to compute summaries such as mean, median, sum, or zonal statistics of a datacube
  • Math and logic processes for calculations, conditions, and comparisons.
  • Reproject and resample processes to align data spatially or temporally.
  • Masking processes to exclude invalid or unwanted data.
  • Vector processes for geometry-based operations.
  • UDF-related processes for more advanced custom logic.
  • Export processes to save or publish results.

The official process definitions are maintained centrally by the openEO project in the Open-EO openeo-processes repository. For everyday use, the easiest entry point is the rendered reference at processes.openeo.org, which tracks the latest released specification.

NoteNote

The openEO process reference lists the processes defined by the openEO project. A specific backend may support all, some, or only a subset of them, and may also provide additional backend-specific processes.

Embedded process reference

The standardised openEO processes are embedded below:

If the embedded reference does not load in your browser, open it directly at https://processes.openeo.org/.

Process families at a glance

The full reference is extensive, so it helps to know the main families of processes offered by the openEO API.

Process family What it is for Typical examples
Import Bring data into a workflow load_collection, load_stac, load_geojson, load_url
Filter Restrict data before heavy processing filter_temporal, filter_bbox, filter_spatial, filter_bands
Cubes Transform or restructure data cubes apply, apply_dimension, merge_cubes, rename_labels
Aggregate and reduce Summarize data over time, space, or dimensions aggregate_temporal, aggregate_spatial, reduce_dimension, reduce_spatial
Math and logic Perform calculations and conditions add, divide, normalized_difference, if, eq
Reproject and resample Align data in space or time resample_spatial, resample_cube_spatial, resample_cube_temporal
Masks Exclude invalid or unwanted values mask, mask_polygon
Vector Work with geometries and vector data vector_buffer, vector_reproject, filter_vector
UDF and external processing Inject custom logic or external compute run_udf, run_udf_externally, run_ogcapi
Export and STAC Save, publish, or package results save_result, export_workspace, stac_modify
Domain-specific EO processes Use EO-focused higher-level operations ndvi, sar_backscatter, cloud_detection, climatological_normal

UDF-related process extension example

A simple way to think about processes

As mentioned earlier, openEO processes are the building blocks of workflows. You can think of an openEO workflow as a chain of processes that implement the questions you ask the system:

  1. Which process do I need to load the data?
  2. How do I filter the data to the relevant spatial and temporal extent?
  3. Which calculations do I want to perform?
  4. How do I want to summarise or export the result?

Each of those steps is implemented with one or more processes.

For example, a basic workflow might look like this:

load_collection
    -> filter_temporal
    -> filter_bbox
    -> ndvi
    -> aggregate_temporal_period
    -> save_result

This means:

  • load a collection,
  • keep only the dates you need,
  • keep only the area you need,
  • compute a vegetation index,
  • summarize it over time, and
  • export the result.

Standardized, but not identical everywhere

One of the strengths of openEO is that the same workflow idea can be used across multiple services. However, process support can differ across backends; therefore, it is recommended always to check the capabilities of the specific backend you are using.

Differences may include:

  • which standardised processes are implemented,
  • whether synchronous processing is supported,
  • which experimental or advanced processes are available,
  • whether UDFs or UDPs are supported,
  • which input and output formats are available, and
  • whether a backend exposes additional provider-specific processes.

The differences between backends are intentional and expected. Though openEO tries to standardise the processing language, each backend may implement it differently.

If you want more details about how services differ across backends, see the Backends page.

Process profiles and support levels

Not every service is expected to implement the same full set of processes. To make support levels easier to understand, openEO defines process profiles.

These profiles group capabilities into levels such as:

  • L1 Minimal for basic openEO compliance,
  • L2 Recommended for practical day-to-day usage,
  • L3 Advanced for more demanding workflows, and
  • L4 Above and Beyond for specialised and highly advanced use cases.

For users, the main benefit of profiles is that they help explain why two backends can both be openEO-compatible yet support different sets of processes.

The main profile levels can be summarised like this:

Profile level What it usually means for users
L1 Minimal Basic openEO compliance and the minimum process set needed for simple workflows.
L2 Recommended A more practical set of processes for everyday EO work, including common filtering, aggregation, and data-cube operations.
L3 Advanced More advanced process support for richer workflows, including broader callback handling, STAC-related functionality, and advanced cube operations.
L4 Above and Beyond Specialised and high-end capabilities for demanding or niche workflows.

There are also sub-profiles for particular needs such as raster processing, vector processing, date and time operations, text handling, machine learning, UDFs, climatology, and analysis-ready data.

Some platforms also defined extra requirements on top of the general openEO profiles. A useful example is the former openEO Platform federation guidance, which introduced additional expectation levels often referred to as L2P, L3P, and L4P.

Those platform-specific levels can be summarised as follows:

Additional platform level Practical meaning
L2P A backend not only supports the recommended process set, but is also expected to handle core raster workflows reliably at a meaningful scale. This typically includes common processes such as load_collection, filter_temporal, filter_bbox, filter_bands, apply, aggregate_temporal, aggregate_spatial, mask, ndvi, reduce_dimension, resample_spatial, and save_result.
L3P The backend also supports more advanced capabilities important for advanced workflows, such as apply_neighborhood, load_stac, filter_labels, reduce_spatial, resample_cube_temporal, and run_udf.
L4P The backend additionally supports more specialised or high-end functionality such as atmospheric_correction, load_uploaded_files, load_url, and sar_backscatter.

In practice, these extra platform-specific levels were useful because they signalled more than simple endpoint availability: they indicated that important processes were expected to work robustly on larger, realistic Earth Observation workloads.

How to discover process support in practice

When you connect to a backend, you should not assume that every documented process is available exactly as shown in the generic reference.

Instead, check support using one or more of these approaches:

  • Inspect the backend documentation.
  • Use the backend metadata or capability endpoints.
  • Use client-library helpers such as list_processes or describe_process.

Backends can implement a varying set of processes, including non-standardised ones.

Where to learn how to use processes

For practical usage, the next place to look is the documentation that shows how they are used on data cubes.

The most relevant section is:

That section explains how processes are used for common workflow steps such as:

  • preprocessing,
  • spatial operations,
  • temporal operations,
  • spectral operations,
  • cube manipulation,
  • UDFs,
  • machine learning, and
  • job execution.

What to do next

Depending on what you want to achieve, a sensible next step is one of the following:
